Conditional (IF/THEN) Fields

Conditional fields let a document react to what the signer does. A controlling checkbox decides whether one or more dependent fields are shown or unlocked, so signers only fill in the fields that actually apply to them.

A classic example: a reviewer checks "Request changes", and only then does a text box appear asking them to explain what to change. If they leave the box unchecked, the text box never gets in the way.

Conditional logic is expressed entirely through the optional metadata object on a field, so it works anywhere fields are accepted — the single-step Prepare for Signing and Prepare for Review routes and the Bulk API.

How it works​

A conditional relationship always has two halves:

  1. A controlling checkbox — a field of type: "checkbox" that carries a stable identifier, metadata.fieldKey.
  2. One or more dependent fields — each carries a metadata.conditional rule whose controllingFieldKey matches the checkbox's fieldKey. The rule names the condition (operator) and what happens when it is met (action).

One checkbox can control any number of dependent fields — give them all the same controllingFieldKey.

The metadata contract​

metadata: {
  // On a CONTROLLING checkbox (type: "checkbox"):
  fieldKey: "request_changes",

  // On a DEPENDENT field:
  conditional: {
    controllingFieldKey: "request_changes", // = the checkbox's fieldKey
    operator: "is_checked",                 // "is_checked" | "is_not_checked"
    action: "show"                          // "show" | "unlock"
  }
}
PropertyValuesMeaning
fieldKeyany non-empty stringStable id on the controlling checkbox. Dependent fields point at this.
conditional.controllingFieldKeya checkbox's fieldKeyWhich checkbox this field depends on. Required and must be non-empty.
conditional.operatoris_checked, is_not_checkedThe condition evaluated against that checkbox.
conditional.actionshow, unlockWhat happens to this field when the condition is met.

show vs. unlock​

actionStarting state of the dependent fieldWhen the condition is met
showHiddenThe field appears
unlockVisible but read-onlyThe field becomes editable

Use show when the field is irrelevant unless the box is set (a reason box that only matters if changes are requested). Use unlock when the field should always be visible for context but must not be edited until the signer opts in (an amount field that stays greyed out until "Override default" is checked).

Worked example: a checkbox reveals a text field​

The reviewer sees a "Request changes" checkbox. Only if they check it does the "Please explain" text field appear.

const fields = JSON.stringify([
  // 1) Controlling checkbox — gets a stable fieldKey
  {
    recipientEmail: "reviewer@company.com",
    type: "checkbox",
    page: 1,
    x: 100,
    y: 400,
    width: 20,
    height: 20,
    required: false,
    metadata: {
      fieldKey: "request_changes",
    },
  },
  // 2) Dependent text field — HIDDEN until "request_changes" is checked
  {
    recipientEmail: "reviewer@company.com",
    type: "text",
    page: 1,
    x: 130,
    y: 400,
    width: 300,
    height: 60,
    required: false,
    defaultValue: "",
    metadata: {
      conditional: {
        controllingFieldKey: "request_changes",
        operator: "is_checked",
        action: "show",
      },
    },
  },
]);
formData.append("fields", fields);

When the reviewer checks the box, the text field appears. Uncheck it and the field disappears again.

Worked example: a checkbox unlocks a locked field​

Here the amount field is always visible so the signer can see the default, but it stays read-only until they check "Override default amount".

const fields = JSON.stringify([
  // Controlling checkbox
  {
    recipientEmail: "signer@company.com",
    type: "checkbox",
    page: 1,
    x: 100,
    y: 500,
    width: 20,
    height: 20,
    required: false,
    metadata: {
      fieldKey: "override_amount",
    },
  },
  // Dependent amount field — VISIBLE but LOCKED until the box is checked
  {
    recipientEmail: "signer@company.com",
    type: "text",
    page: 1,
    x: 130,
    y: 500,
    width: 150,
    height: 30,
    required: false,
    defaultValue: "1000.00",
    metadata: {
      conditional: {
        controllingFieldKey: "override_amount",
        operator: "is_checked",
        action: "unlock",
      },
    },
  },
]);
formData.append("fields", fields);

Reveal a field when a box is cleared​

Set operator: "is_not_checked" to invert the logic. For example, an "I do not consent" checkbox can reveal a text field asking the signer to explain, only when consent is not given:

{
  metadata: {
    conditional: {
      controllingFieldKey: "consent",
      operator: "is_not_checked",
      action: "show",
    },
  },
}

Validation and fail-open behavior​

The API validates the shape of every conditional rule before creating the document. A malformed rule is rejected with HTTP 400 and the type InvalidConditionalRule. A rule is malformed when:

  • operator is anything other than "is_checked" or "is_not_checked", or
  • action is anything other than "show" or "unlock", or
  • controllingFieldKey is missing or empty.

The response body names the offending field and the exact problem:

{
  "message": "Field 2: metadata.conditional.operator must be one of: is_checked, is_not_checked",
  "type": "InvalidConditionalRule"
}
A well-formed rule with a wrong key fails open

The API does not verify that a rule's controllingFieldKey actually matches a checkbox in the request. If it doesn't match any checkbox's fieldKey, the rule fails open: the dependent field stays fully visible and editable, exactly as if it had no rule, and no error is returned. A typo in controllingFieldKey therefore silently disables the condition instead of blocking the send. Always confirm each dependent field's controllingFieldKey exactly matches an existing checkbox's fieldKey.

Tips​

  • The controlling field must be a checkbox (type: "checkbox"). Only checkboxes can hold a controlling fieldKey.
  • Keep fieldKey values short, stable, and unique within a document (request_changes, override_amount, consent).
  • A dependent field that is required: true but hidden via action: "show" is only enforced once it becomes visible — don't rely on a hidden required field to block completion.
  • The controlling checkbox and its dependent fields should generally belong to the same recipient so the same signer both toggles the box and fills the revealed field.
